Velbus HDR-60-15 Power Supply VMBPSU-2

Velleman
VMBPSU-2
5410329433499
    5-10 Days
  • Description
  • More Details
A 54 Watt Switch mode power supply (11..13V). It has the same functionality as VMBTR1 and VMB3PS combination and provides a suitable voltage for your Velbus installation. However, the voltage is slightly lower which makes it less suitable for very long and thin cabling. *set to 13.2V output for Velbus system.

Specifications

  • input:
    • input voltage: 88…264Vac/47…63Hz
    • efficiency: 82% (Typ.)
  • output:
    • isolated DC output: 11.1 to 13.2V adjustable*
    • rated power: 54W (4.5A@12V)
    • output ripple: < 120mVpp
    • double output connector
  • operating temperature: -20...60°C
  • protection: short-circuit, overload, overvoltage
  • isolation class: II
  • dimensions (LxWxH): 93 x 78 x 56mm / 3.7 x 3 x 2.2"
